JUKI LK-1900BN-HS High Speed Electronic Tacker with 40mm x 30mm Max Sewing Field, Made in Japan
The JUKI LK-1900BN-HS is the latest model in this superior class of JUKI electronic tackers spanning some 40 year history. The machine listed and priced is the HS class configured to sew heavier materials with ease.
Ideal for those in the defense, tactical gear, dog collar, medical device, backpack, outdoor gear and special application industries, the machine has been proven to withstand extremely heavy use without needing unscheduled service. The machine is of superior build quality and still assembled in Japan.
This JUKI tacker arrives with 50 pre-programmed patterns in the control panel memory – list of patterns can be found below. The standard factory clamp setup is the 1″ East-West tacking clamp. We have professionally set up multiples of these machines for a variety of sewing applications and if you need any custom clamping or programming – we can get you set up before we ship the machine.
Contact us at your convenience at 469-879-6213 (or vie e-mail) with your requirements.
If your application requires no extra setup, feel free to purchase through our web site and you should receive your machine – complete and fully assembled – within 10 to 14 days.
-
Higher productivity
The machine achieves sewing speed of 3,200sti/min. The machine’s starting, stopping, thread-trimming and automatic presser lifting speeds have been increased to significantly shorten total cycle time.
-
Excellent workability and operability
(Low-noise and low-vibration)- The direct-drive head (with no belt), which is directly connected to a compact AC servomotor, achieves outstanding. This head helps create a comfortable working environment with reduced vibration and noise.
- The arm section of the machine head is fitted with a hand pulley. This allows the operator to visually check the needle entry points.
-
Excellent seam quality
Needle thread grasping mechanism helps produce consistent knot tying at the beginning of sewing. (This device has been factory-set to “invoking prohibited” status at the time of delivery.)
-
The sewing starting point can be corrected
In cases where the needle entry point for button sewing is to be corrected, the sewing starting point can be corrected without the adjustment of the relevant mechanism.
-
Auto-lifter mechanism utilizing a system
- The machine is provided as standard with auto-lifter that uses a stepping-motor system. This helps reduce operator fatigue.
- It is also possible to change over the stroke of the auto-lifter from a onestep stroke to a double-step stroke, which offers easier positioning of a material on the machine. For the double-step stroke, an intermediate stopping height can be established on the operation panel.
- The work clamp foot lift can be set to a maximum of 17mm. (Standard 14mm)
-
Oil stains are eliminated
- Thanks to our advanced dry-head technology, the frame (needle bar and thread take-up) no longer requires lubrication. This prevents the material from being stained with lubricating oil.
- Just a small quantity of clean oil is supplied from the oil tank to the hook.
-
Eco-friendly power saving
An encoder is installed in the pulse motor, thereby achieving substantially improved power-consumption saving.
-
LED Light
The LED light can adjust the light intensity to 5 levels, and Off setting is also possible.
The operator can set the brightness which is easy to work, improving work efficiency.
-
Optimal specifications are available according to the material
Since the H specification has enhanced needle penetration, the ability to handle thick materials has been further improved.
With the W specification, the use of a cauldron reduces the frequency of bobbin thread replacement, enabling efficient work.
| Model name | LK-1900BN-HS | LK-1900BN-WS | ||
|---|---|---|---|---|
| Application | For heavy-weight materials | With large hook for heavy-weight materials | ||
| Max. sewing speed | 3,200sti/min* | 2,700sti/min* | ||
| Sewing area | 30mm (L) × 40mm (W) | |||
| Stitch length | 0.1~10mm (0.1mm step) | |||
| Needle bar stroke | 41.2mm | |||
| Lift of the work clamp foot | Standard 14mm (17mm when the reverse-rotation needle-up function) | |||
| Auto-lifter | Provided as standard (stepping motor type) | |||
| Needle thread tension | Active tension (electronic thread tension control system) | |||
| Needle (at the time of delivery) | DP×17 (#21) | |||
| Hook | Standard shuttle hook | Large shuttle hook | ||
| Number of stitches that can be stored in memory |
Max. 20,000 stitches | |||
| Number of standard patterns | 51 patterns | |||
| Number of data that can be input | 200 patterns (for up to 150 patterns, sewing data can be added.) | |||
| Enlarging/Reducing facility | 20~200% (1% step), Pattern enlargement/reduction can be done by increasing/decreasing the stitch length |
|||
| Memory method | Internal-organs memory | |||
| Bobbin thread counter | Provided as standard (up/down method) | |||
| Lubrication | Hook: minute-quantity lubrication | |||
| Lubricating oil | JUKI New Defrix Oil No.2 (equivalent to ISO VG32) | |||
| Sewing machine motor | 450W compact AC servomotor (direct-drive system) | |||
| Power consumption | 250VA | |||
| Weight | Machine head (include motor) 42kg, Control box 5.6kg | |||
This JUKI LK-1900BN-HS electronic tacker is priced and ships complete and fully assembled:
- Head – Mounted on the Stand, Sewn Off and Tested
- Factory Set 1″ East West Tacking Clamp
- Control Panel
- Table Top
- Stand
- 110 Volt Standard Power Plug
- Thread Stand
- Extra Needles
- Extra Bobbins
- Oil
- Factory Supplied Tools and Manuals
Contact SEWMAX at 469-879-6213 for more details or to purchase this machine over the phone.
